The Fortpro Air Spring F245593 is a high quality, heavy duty air suspension component for automotive vehicles. With its robust design and reinforced synthetic rubber membrane, it offers excellent load capacity and fatigue resistance. It allows you to adjust the height and stiffness of the suspension to adapt to different load and terrain conditions. Provides comfort, stability and driving safety.

Specifications:

• Brand: Fortpro
• Part Type: Air Spring / Air Spring Bag / Suspension Air Spring
• Vehicle Type: Semi-Trucks, Heavy-Duty Trucks
• Part OEM: 8729, W013588729, W01-358-8729
• Position: Primary Truck & Trailer Axle
• Air Spring Style: 1T Reversible Sleeve
• Piston Type: Composite
• Bead Plate Diameter Bottom: 10.16"
• Bead Plate Diameter Top: 10.38"
• Collapsed Height: 4.70"
• Max. Height: 14.00"
• Part Diameter: 10.12"
• Piston Height: 3.20"
• Stud Configuration-Bottom: 1
• Stud Configuration - Top: 2
• Weight:: 13.15 lbs
• Application: Meritor 202796 (GY 1R13-130)
• VMRS: 016-008-000

CrossReference:

• Automann: 566CT77963, 566ER8729, AB1DK25D8729, AB1DK28C8617
• Contitech: 1010B13S513
• Dayton Parts Batco: 1R13130
• Firestone: 8729, W013588729, W01-358-8729
• Goodyear: 1R13130, 1R13130
• Meritor: FS8729
